Factory Used Lifting Equipment Gantry Crane 10 Ton for sale in price $4000

The 10 ton gantry crane used for factory work is priced at $4000, and this gantry crane has been sold to Singapore with the model MH. If you plan to purchase a 10 ton gantry crane, you can check the detailed parameters of our gantry crane below. We provide a one-year warranty for this gantry crane, which is mainly used in workplaces such as Building Material Shops, Manufacturing Plant, Construction Works, Energy&Mining, Other, etc. in Southeast Asian countries.

Single Box Girder gantry crane is the kind of gantry crane built atop a gantry that can straddle an object or workspace indoor or outdoor applications. Single Box Girder gantry crane is specially engineered to support the bridge and the electric hoist by strong steel legs instead of moving on suspended runways. The gantry crane legs travel on fixed rails embedded in, or laid on top of the floor or on the wheels to move the gantry around your facility which provide an flexible way to lift materials anywhere.

NANTE Single Box Girder gantry crane are designed with the highest engineering standards for safety and high performance by advanced technology. NANTE manufactures and supplies custom single girder gantry crane with the capacity up to 20 tons and span up to 31.5 meters for your demands.

------------------------------------------Design and Manufacturing Feature---------------------------------------

Design Code:

NANTE's Single Girder Low headroom Gantry Crane follows the design code of FEM, CMAA, ISO EN, BS, GB standard.

Hoist:

Compact structure, smooth operation, accurate positioning, high Safety reliability, and Maintenance-friendly.

Girder:

Compact Design and low weight, use Q355B steel material(ISO EN S355, DIN ST52, ASTM A 572 Grade 50), welding specification follows ISO 15614, AWS D14.1, deflection can from 1/700 ~ 1/1000, MT or PT is requested for Fillet welding and UT is requested for joint welding.

End Carriage:

Direct Driving design with high transmission efficiency. Using hollow tube for the steel housing. Wheel material is alloy steel with proper heat treatment which is more stable and durable.

Gear Motor:

Worldwide top brand gear motor to make sure the quality, IP55, F insulation class, overheat protection, manual release bar, and equipped with electro-magnetic brake.

Control Panel:

Follow IEC standard, IP55 powder coating high quality enclosure, socket plug-in for easy connection, DIN standard terminal, international brand for the inverter, MCB, Contact and electrical devices on the panel.

Festoon System:

Double line Galvanized C track system with flexible flat cable, one line for hoist power and signal transmission, one line for the pendent control trolley movement. No-welding claw is design for the brackets of the festoon system fixing.

Safety Protection Functions:

NANTE single girder Gantry Crane include a lot of protection functions, like Overheat protection for the lifting, load cell type overload limit switch, up&down position limit switch, cross limit switch for the cross travel and long travel. Phase sequence relay, and other optional functions, like crane monitoring system, LED load displayer.

Controls:

NANTE single girder Gantry Crane can offer both options of remote control and pendent control.

Anti-corrosive Treatment:

Shoot Blasting follow ISO8501-1 SA2.5 class, roughness follow ISO 8503 G class, clearness follow 8502-3 Level II. Use top brand's Rich zinc epoxy painting for the prime, middle layer coating. Use polyurethane topcoat for the finished layer coating. All NANTE painters are trained or inspected by NACE or FROSIO level II Inspector.

----------------------------------------------------- Application ---------------------------------------------------------

Single Box Girder Gantry Crane is the ideal material lifting and transporting equipment for indoor and outdoor applications such as mining, general fabrication, train building yards, precast concrete and ship building industries, or special outdoor projects like steel mills where overhead room may be an issue.
